Kooltube

Transport Refrigeration with Confidence

The Kooltube is a holdover or latent heat storage system. The completed unit comprises a single phase or three phase condensing set coupled to eutectic beams mounted internally to the roof of the body. The Kooltube is one of the simplest refrigeration systems and has been around in its basic configuration for many years. Simply, it can be compared to a block of ice in a glass of water or to the freezer pack which you freeze in your fridge at home and put into a cooler box to keep your drinks cold. The system is plugged into a electrical supply until the tubes are properly frozen, unplugged, and then the vehicle used for its delivery round.

Highlights

Kooltube

Latent heat storage system, ideal for ice cream delivery trucks and similar applications
Bulkhead or undermount condensing sets according to application requirement, running on 220V 1~/380V 3~
Extruded aluminium tubes containing a non-toxic eutectic solution
Tubes mounted under the roof with certain advantages: wide and high backdoor for fast loading, no partitions, easy cleaning as no obstacles on floor or walls

Characteristics

Silent operation
Low maintenance
Unit longevity
On road emission free
Lower running costs
Minimal wearing parts
Assured refrigeration
Electronic expansion value

Beams

The Kooltube is extruded aluminium containing a non-toxic eutectic solution.
A wide range of solutions is available for various temperature applications.

Condensing set

Semi-hermetic compressor
Simple accessible controls
Nose or undermount
Auto phase detection and correction

Unit capacitiy and mass

The length of the tubes necessary to provide optimum refrigeration performance must be calculated by your dealer.

Required information

Internal body dimensions
Required box temperature
Holdover period required
Pull down time available
Number of door openings per day
Insulation type and thickness
